Release Notes

4D v20 R4​

Read What’s new in 4D v20 R4, the blog post that lists all new features and enhancements in 4D v20 R4.

Highlights​

Behavior changes​

  • Using a legacy syntax for declaring parameters (e.g. C_TEXT($1) or var $1 : Text) is now deprecated and generates warnings at code typing, syntax checking, and compilation steps.
  • In the updated OpenSSL library, the default SSL/TLS security level has been changed from 1 to 2. RSA, DSA and DH keys of 1024 bits and above and less than 2048 bits as well as ECC keys of 160 bits and above and less than 224 bits are now no longer allowed. By default, TLS compression was already disabled in previous OpenSSL versions. At security level 2 it cannot be enabled.

4D v20 R3​

Read What’s new in 4D v20 R3, the blog post that lists all new features and enhancements in 4D v20 R3.

Highlights​

Behavior changes​

  • Some errors were catchable by your error handling method in interpreted mode only. A fix has been done, so that the following errors will now be caught also in compiled mode: Indice out of range, Type incompatible, and Dereferencing a Null pointer. However, for such errors on Intel processors, the procedure is still interrupted as before, whereas on Apple Silicon processors the procedure is only interrupted if you call the ABORT command.
  • 4D no longer includes an internal PHP interpreter. You need to set up and run your own PHP interpreter to use PHP commands.

4D v20 R2​

Read What’s new in 4D v20 R2, the blog post that lists all new features and enhancements in 4D v20 R2.

Security Note

If your 4D applications use TLS connections, it is recommended that you upgrade to 4D v20 R2 HF1 build 100440 or higher. For more information, refer to this Security bulletin.

Highlights​

Behavior changes​

  • Warning: The starting offset value of 4D.FileHandle objects was incorrectly set to 1 instead of 0. A fix has been made in 4D as of versions 20.1 HF1 and 20 R2 and the value is now 0.

4D v20.x​

Read What’s new in 4D v20, the blog post that lists all new features and enhancements in 4D v20.

Minimal client version for 4D Server v20.2 and later

For internal reasons, the version of remote clients connecting to 4D Server v20.2 and later must be at least 4D v20.2.

Security Note

If your 4D applications use TLS connections, it is recommended that you upgrade to 4D v20.2 LTS build 100956 or higher. For more information, refer to this Security bulletin.

Index rebuild warning​

4D v20 includes an ICU library update (see below) which will force an automatic rebuild of indexes of type alpha, text, and object. Depending on the size of the data file, this operation can take a while and may require to be planned.

4D v20.1 index rebuild and client/server versions

4D v20.1 also includes an ICU library update, which has the following consequences:

  • It will force an automatic rebuild of indexes of type alpha, text, and object.
  • Because of sorting consistency, it requires that 4D remote clients and 4D Server use the same version: only remote 4D v20.1 can connect to 4D Server v20.1 and vice versa.

Highlights​

Behavior changes​

  • As of v20.2, 4D v20 LTS is no longer compatible with Windows Server 2012 R2.
  • Warning: The starting offset value of 4D.FileHandle objects was incorrectly set to 1 instead of 0. A fix has been made in 4D as of versions 20.1 HF1 and 20 R2 and the value is now 0.
  • For HTTP RFC compliance, HTTPRequestClass.response.headers property now returns all header names in lowercase. If you want your code to continue working as before, use the new HTTPRequestClass.response.rawHeaders property.
  • TLS certificates are now automatically validated by 4D when sending HTTP requests with 4D.HTTPRequest.new(), and rejected with an error if they are invalid. A new option property allows you to control this validation.
  • TLS v1.0 and TLS v1.1 are deprecated, they are no longer supported as Min TLS version on 4D Server. Version 1.3 is now selected by default and is automatically used if _o_TLSv1_0 or _o_TLSv1_1 constants are set with SET DATABASE PARAMETER.
  • For consistency, all buttons, checkboxes, and radio buttons are now rendered with a "3D" type at runtime: respectively Object type 3D button, Object type 3D checkbox, and Object type 3D radio button are returned by OBJECT Get type for these objects.
  • As of 4D v20, 4D for Mobile is no longer installed by default in the 4D environment. To benefit from the 4D for Mobile development features in 4D, you need to install the 4D Mobile App component in the "Components" folder of your projects. If a converted project uses features from the 4D Mobile App Server component, make sure you also install it in the "Components" folder of the project.

4D v19 R8​

Read What’s new in 4D v19 R8, the blog post that lists all new features and enhancements in 4D v19 R8.

Highlights​

Behavior changes​

4D v19 R7​

Read What’s new in 4D v19 R7, the blog post that lists all new features and enhancements in 4D v19 R7.

Highlights​

Behavior changes​

  • For consistency with standard interfaces (e.g. OS file explorers), list box rules for row selection/drag and drop have been modified. A continuous or discontinuous selection of rows can be dragged by simply clicking on and moving a selected row; the Alt key is not longer necessary (but can still be used like in previous previous). When the Shift or Ctrl/Command key is pressed, a mouse click is taken into account when the click is down. For more information on drag and drop in list boxes, you can refer to this blog post and download this HDI 4D project.
  • The 4D internal build numbering has been modified as of 4D v19 R7:
    • releases up to 4D v19 R6 (included) are numbered 282xxx,
    • releases from 4D v19 R7 will be numbered 100xxx.
      Note that a specific 4D version is still uniquely identified by a branch name and a build number. The build number increases chronologically.
  • The ability to use Wakanda/4D Mobile REST protocol to call a project method has been removed. You can use ORDA data model class functions or /4DACTION urls instead.

4D v19 R6​

4D v19 R5​

  • The project directory.json file can now be embedded in the server at build time, allowing you to deploy a client/server application with a basic security user and group configuration.
  • You can now deselect useless modules in your built applications.
  • The MeCab library is included by default in all 4D applications on macOS. In previous releases, this library, specifically designed to manage Japanese text, was only available in the Japanese version of 4D on macOS. If you do not need this library in your final applications, you can now deselect it.
  • Client/Server optimization: New class functions allow you to handle the ORDA cache and the contents of an optimization context. See Preconfiguring contexts and ORDA Cache for more information.

    These functions are intended for developers who need to customize ORDA default features for specific configurations. In most cases, you will not need to use them.

  • DataClass class: The new .getCount() function returns the number of entities in a dataclass.
  • The 4DDiagnosticLog.txt file only records high-level information by default (INFO level. You can now select the information level to record (for example DEBUG level information) using the Diagnostic log level selector of the SET DATABASE PARAMETER command or the log configuration file.
  • Calling Use() on a non-shared object or a non-shared collection does nothing (it no longer generates an error). Thus, it is now useless to test if the object or collection passed to Use() is actually shared.
  • For clarification purposes, two SQL commands have been prefixed: GET DATA SOURCE LIST has been renamed to SQL GET DATA SOURCE LIST, Get current data source has been renamed to SQL Get current data source.
  • 4D View Pro:
  • Web areas:
    • New Windows system rendering engine: Web Areas using the Windows system rendering engine are now based upon Microsoft Edge WebView2. This impacts the following features:
      • The WA Create URL history menu and WA GET URL HISTORY commands only return the current URL.
      • The Progression variable is no longer updated.
      • Drag and drop features are handled by a Windows API which is tagged "experimental" by Microsoft. Consequently, web areas may not work as expected when this API is not installed: Drag and drop may seem allowed even when the WA enable URL drop preference has been set to False. However, the drop action is blocked by default, and you can control the allowed URLs using the On Window Opening Denied event (see below).
    • (Windows only) When the user selects Print... from a web area using the embedded web rendering engine, a new print settings window is now displayed.
    • To reflect their actual effect in web areas (increase or decrease page zoom level), two commands have been renamed: WA SET PAGE TEXT LARGER has been renamed WA ZOOM IN, WA SET PAGE TEXT SMALLER has been renamed WA ZOOM OUT.
    • Enhanced security in web areas that use the embedded web rendering engine or the Windows system rendering engine (based on Microsoft Edge WebView2):
      • CORS policies now apply when accessing files on disk in web areas. For example, when opening a .html file with WA OPEN URL, that .html file cannot contain links that point to files outside its folder
      • Dropping external contents in web areas is now always blocked and triggers the On Window Opening Denied event when the WA enable URL drop preference is set to True (when set to False, the WA enable URL drop preference only modifies the drop cursor icon and filters the On Window Opening Denied event). To allow a drop action, you need to execute additional code in the object method of the web area:
WA OPEN URL(*;"WebArea";WA Get last filtered URL(*;"WebArea"))

4D v19 R4​

  • Alias attributes are available in ORDA classes.
  • Support for break and continue statements in loops.
  • Support for return statement and return expression to return values.
  • Support for compound assignment operators, short-circuit operators, and ternary operator
  • The Code Editor now includes an dropdown tool and supports markers for better code navigation.
  • New Preferences: Include tokens in project source files and Show clipboards option on the Methods page.
  • New REST request to lock/unlock entities.
  • 4D View Pro chapter added with new commands: VP Copy to object, VP MOVE CELLS, VP PASTE FROM OBJECT.
  • New SystemWorker class.
  • The Alias selection constant has been renamed Allow alias files to resolve a conflict resulting from the support of alias attributes in ORDA.
  • For better compliance with ORDA specifications, the Map NULL values to blank values field property is now unchecked by default in databases created with 4D v19 R4 and higher. You can also enable this default behavior in your databases converted from previous versions by selecting the Map NULL values to blank values unchecked by default at field creation compatibility setting. Working with Null values is now recommended since they are fully supported by ORDA.
  • Because of the support of the ternary operator, the colon ":" is no longer allowed in variable, field, constant, function, plugin and project method names. If your database/project contains identifiers with colons, you must replace them before converting it to v19 R4 or higher, otherwise errors may occur in your code. For example, if you have a variable named a:b, it could be interpreted as ternary operator syntax:
$value:=($size>1000)? a:b // Here 'a:b' is viewed as a ternary operator.

4D v19 R3​

// "concate" function of myClass
Function concate ($param1 : Text ; $param2 : Text)
ALERT($param1+" "+$param2)
  // Calling method
 $class:=cs.myClass.new()
 $class.concate("Hello";" world") // Displays "Hello world"
 $class.concate("Hello") // Displays "Hello "
 $class.concate() // Displays " "

For detailed information, please refer to this blog post. To benefit from this overall simplification, you need to recompile both calling and called methods; thus components must be recompiled.

  • Debugging web server sessions is easier on 4D Server.

  • The new 4D NetKit component allows you to connect to third-party APIs such as Microsoft Graph.

  • 4D v19 R3 uses a stronger hashing algorithm for 4D user passwords: Bcrypt. This new algorithm is automatically used when a password is changed using the Tool Box, the CHANGE PASSWORD command, or the Set user properties command. Once a password is modified, opening the database with a version prior to 4D v19 R3 will cause an authentication denial for this account. If you use 4D passwords, it is highly recommended to backup the .4db file (binary databases) or directory.json file (projects) before upgrading to 4D v19 R3 or later.

  • For accuracy, the 4D digest constant has been renamed 4D REST digest.

  • End-of-line and BOM management for XML commands: When opened in 4D v19 R3, projects or databases created with previous releases behave differently regarding default end-of-line characters and BOM management in XML documents: line feed (LF) characters are used instead of CR (on macOS), and byte order marks (BOM) are not included. This allows a better compatibility with VCS tools. If necessary, you can restore the v19 R2 behavior using the XML SET OPTIONS command. In projects or databases converted from versions prior to 19 R2, these options are managed by two compatibility settings.

  • Runtime Explorer shortcut removed in built projects: The Cmd/Ctrl+Shift+F9 shortcut does no longer display the Runtime Explorer window in single-user merged project applications. This shortcut can now be a user application shortcut. You can call the Runtime Explorer window using the new OPEN RUNTIME EXPLORER command.

  • Extended debugging capabilities with 4D Server: In interpreted mode, 4D Server can now debug all kinds of processes, including scalable web sessions. This is available when the debugger is attached to the server or to a remote client.
    Warning: In interpreted mode, in order to make extented debugging available on the server machine, all server processes are now automatically executed in cooperative mode when the debugger is attached to the server (default setting). This can have a significant impact on the performance of your converted applications when they run with 4D Server v19 R3 and higher. To restore preemptive execution on the server in this case, all you need to do is detach the debugger from the server (and attach it to a remote client if necessary).

  • On Windows, 4D projects and databases created with 4D v19 R3 and higher use the DirectWrite API in forms. This API improves text rendering, especially in high DPI configurations. DirectWrite is used for text rendering with static and input text, checkboxes, buttons, and radio buttons. Note that listboxes already use DirectWrite. A compatibility option allows you to enable DirectWrite in projects and databases created with previous 4D versions.

  • If you use components compiled with 4D v19.0 for Silicon (Apple ARM CPUs) which call the Count parameters command, we recommend to recompile them with 4D v19 R3 to provide compatibility with 4D v19 R3 and future releases. If a component is not compiled for Silicon, there is no need to recompile.

4D v19 R2​

Previous releases​

Click to see the release notes for previous versions

4D v19​

Security Note

If your 4D applications use TLS connections, it is recommended that you upgrade to 4D v19.7 LTS build 288986 or higher. For more information, refer to this Security bulletin.

4D v18 R6​

Library table​

LibraryCurrent versionUpdated in 4DComment
ICU73.220.1This major upgrade forces an automatic rebuild of alphanumeric, text and object indexes.
CEF11820 R3Chromium 5993
Hunspell1.7.220Used for spell checking in 4D forms and 4D Write Pro
PDFWriter4.320FreeType dependency in 12.2.1
SpreadJS16.2.620 R44D View Pro engine
OpenSSL3.2.020 R4Default TLS/SSL security level has been upgraded. See Behavior changes for release 20 R4
libZip1.9.220Used by zip class, 4D Write Pro, svg and serverNet components
LZMA5.4.120
Zlib1.2.1320
webKitWKWebView19
PHP8.2.420
libldap2.6.420 R3
libsasl2.1.2820
